MAG-ic Probe WiFi Thickness Caliper

New for 2021!

 MAG-ic Probe WiFi

Luthiers craft fine wooden instruments and understand that the voice and tone of the final instrument will largely depend on carefully planned thicknesses of the tone wood. MAG-ic Probe has been a trusted electronic thickness caliper used by many Luthier's and other craftsmen since 2012. MAG-ic Probe allows you to measure thicknesses of materials in places where standard calipers cannot fit and also allows you to record your measurements to a computer picture of the instrument and even produce a color contour map.

New for 2021! - MAG-ic Probe can also display the measurements on any phone, tablet or computer that has WiFi capability.

How Does it work?

MAG-ic Probe is a small electronic device that can measure the thickness of non-ferromagnetic materials by using a target magnet. The magnet is placed on one side of the material and the MAG-ic Probe on the other side. The magnet is attracted to the MAG-ic Probe so the measurement will be the thickness of the material at the probe location.

Ideally suited to measuring the thickness of the wooden plates that make up many musical instruments, the magnet can be placed inside the instrument body where standard calipers cannot reach. When the probe is moved along the outside of the instrument, the magnet will follow and will even jump over reasonably sized braces.

MAG-ic Probe is also extensively used in the plastics and composites forming industry.

There are a number of options for displaying or recording these measurements.

1) MAG-ic Probe Software


The free MAG-ic Probe Lite software will allow you to upload a picture of the instrument to your computer. Simply move and aim the mouse pointer at the location on the picture where you are measuring with the MAG-ic Probe, and the measurement will be recorded on the picture. You can map the entire surface of the instrument in this way and print or save the measured image for a permanent record.



The optional MAG-ic Probe PRO software goes further by allowing your measurements to be displayed as a color contour map of the instrument. This makes it easy to instantly see the contour of the plate for progressive shaping or comparative analysis.




2) Display measurements on any WiFi device.

If you do not want to record your measurements and just want to display the measurements as you are shaping or analyzing an instrument, MAG-ic Probe WiFi will now connect to any phone, tablet or computer that has WiFi capability and display the measurements without downloading any apps.


Simply join the MAG-ic Probe WiFi, open the browser on your device and connect to see your measurements in real time.



3) MAG-ic Probe Display unit.

Don't carry a phone? Don't want to bother with WiFi connections?



Well then the optional  New MAG-ic Probe Display unit may be just what you need. This is a small LCD display that will automatically connect to the MAG-ic Probe and display the measurements. It is simple to use and small enough to slip into your pocket.



The MAG-ic Probe Display unit features WiFi and Bluetooth in one device so it will also work with the previous version, the MAG-ic Probe BLE.







  • The MAG-ic Probe WiFi comes with  -
    • 2 magnets, a 1/2" ball for guitars, Cello's, plates or any object where access is not restricted and a 1/4" (6.35mm) cylinder magnet which should fit into most f-holes of violins and mandolins.
    • The MAG-ic  Probe measuring 2.3" x 0.85" (60mm x 22mm).
    • a USB Cable for Attaching to your computer.
    • a Handy padded storage box.
    • Free Downloadable Software - MAG-ic Probe Lite Software allows you to upload a picture of the instrument or object you are measuring on your computer and record each measurement you make to that picture (See Software section for details). You must add the free software to your cart to be able to download it.
  • OPTIONAL -the MAG-ic Probe PRO Software may be purchased which will allow you to transform your completed measurements into a full-color contour map to instantly visualize your thickness planes. (See Software section for details and videos.)



Do you own the previous version, MAG-ic Probe BLE?

 The MAG-ic Probe BLE can also use the MAG-ic Probe Software or the MAG-ic Probe Display module above, but for displaying measurements on a phone there is a 3rd party solution.

A fellow luthier has created a mobile application to display and record measurements on a mobile device for those times you are not near your computer. Search you app store for Magic Caliper

Please note that MAG-ic Probe is not affiliated with the developer of the Magic Caliper app.



You can find the Magic Caliper app on the IOS App store at https://apps.apple.com/us/app/magic-caliper/id1505243118?ls=1

Magic Caliper for Android is also released in the Play Store https://play.google.com/store/apps/magic_caliper





DELIVERY- Please note that delivery can be up to 10 days depending on current schedule and order demand.



Take a look around and see the tutorial videos on the MAG-ic Probe Software page.

Let us know if we can answer any questions by using our contact page in the About US section or by email at info@magicprobe.net
